AUTOSTEM CARTRIDGE RANGE

Generation lll

Mining

Quarries

Civil

Demolition

AutoStem Cartridges

CARTRIDGE RANGE

CONTROL YOUR BLASTING WITH SPECIFIC POWER CHARGES

AutoStem identified a need for a smaller rock breaking cartridge that could be used without air compressors, rock drills, and air hoses. The AutoStem Micro Range of Cartridges was specifically designed for applications where our customers prefer to use hand-held electric or battery powered hand drills, rather than incurring the cost, labour and extra effort in using portable air compressors and handheld rock drills.

The cost of Rock or Concrete breaking using the AutoStem Micro Range is in some cases more than 90% cheaper per cubic meter than conventional hydraulic rock breaking equipment.



The AutoStem Micro Range is perfect for sensitive/urban blasting without sacrificing power. AutoStem Micro Range of Blasting Cartridges are available in 9mm and 17mm diameters suitable for a 10mm and 20mm borehole respectively.

Effective charge weights per cartridge range from 3g – 40g making this the widest range of blasting products in its category globally.

Rock Breaking Cartridge 9mm

The 9mm range of AutoStem Micro

  • Available in 3g, 6g and 9g charges

  • Self-stemming

  • Electric initiation

  • Highly delicate blasting work, rock splitting

  • Max borehole size: 12mm

AutoStem 9mm, 3g Rock Breaking cartridge
Rock Breaking cartridge AutoStem 9mm, 6g
Rock Breaking Cartridge

Product code: 9mm x 3g

Performance: 0.3 - 0.8 m3 / cartridge

Product code: 9mm x 6g

Performance: 0.5 - 1.2 m3 / cartridge

Product code: 9mm x 9g

Performance: 1.0 - 2.0 m3 / cartridge

AutoStem 17mm Long Rock Breaking Cartridge

The 17mm range of AutoStem Micro

  • Available in 20g, 30g and 40g charges

  • Self-stemming

  • Electric initiation

  • More significant blasting work, rock fragmenting

  • Max borehole size: 20mm

AutoStem 17mm, 20g Rock Breaking Cartridge
Rock Breaking Cartridge
NX Burst Rock Breaking cartridge

Product code: 17mm x 20g

Performance: 1.0 - 2.4 m3 / cartridge

Product code: 17mm x 30g

Performance: 2.0 - 3.0 m3 / cartridge

Product code: 17mm x 40g

Performance: 2.5 - 3.6 m3 / cartridge

GENERATION 3

The 35mm Cartridge Range

  • Suitable for borehole sizes up to 40mm

  • Available in 100g, 180g and 300g charges

  • Available with electric initiation and detonator capable initiation

  • Suitable for deep level mining, trenching, civil blasting & demolition

AutoStem 35mm Rock Breaking cartridges

GENERATION 3

The 43mm Cartridge Range

  • Suitable for borehole sizes up to 50mm

  • Available in 350g and 550g charges

  • Available with electric initiation and detonator capable initiation

  • Suitable for deep level mining, tunnelling, embedded rock, quarrying, shallow bench blasting and hard blasting environments.

AutoStem 43mm Rock Breaking cartridges

GENERATION 3

The 83mm & 87mm Cartridge Range

  • Suitable for borehole sizes of 89mm & 93mm

  • Available in 1700g charges

  • Available with electric initiation and detonator capable initiation

  • Suitable for large borehole blasting, benching, mining and quarrying

Rock Breaking cartridge 83mm

Electric and detonator-shocktube product options available

All Gen III products can be integrated with centralised blasting systems

Sequential firing capability utilizing standard explosive accessories

AutoStem Gen III seamlessly integrates into any blasting system, from any supplier, anywhere in the world

Rock Breaking Cartridge AutoStem 35mm with Shock Tube
Rock Breaking Cartridge

Shocktube 35mm

35mm product range with detonator/shocktube integrated

AutoStem 35mm with Shocktube small

Shocktube 43mm

43mm product range with detonator/shocktube integrated

AutoStem 83mm with shocktube

Shocktube 83mm

83mm product range with detonator/shocktube integrated

AUTOSTEM ACCESSORIES

AutoStem Fusehead Igniter
AutoStem Blasting Machine

ELECTRIC IGNITOR (FUSE HEAD) AND INITIATORS

  • Highest quality Fuse Head for reliable ignition

  • Multiple wire lengths available, 1.5m, 3.0m and 5.0m

  • Electrical Resistance: 0.5 ohm

  • Safety Impulse: 8 mj per ohm

  • Initiation Impulse: 16 mj per ohm

  • Safe Electrical Current: 0.45 A

  • Activating Electrical Current: 2.12A

SHOT EXPLODERS / BLASTING MACHINES

1351 model shot exploder

  • 1350V Nominal Firing Voltage

  • 40.0J Nominal Output Energy

  • Firing mechanism: Spring return key switch

  • Up to 250 AutoStem Cartridges in Series

  • Battery Type: Rechargeable NiCd

  • Capacity: Typically 500 firings

  • Charging: Charged from mains power (220V - 240V)

  • Charging time: 14 hours to full charge

  • Unit dimensions: 163mm x 125mm x 66mm

  • Unit mass: 1.9kg

BB75 Blasting Machine
Buzz Mo Continuity Tester

SHOT EXPLODERS / BLASTING MACHINES

BB-75 model shot exploder

  • 340V Nominal Firing Voltage

  • 13 Joules Nominal Output Energy

  • Firing mechanism: Two button firing system with auto abort

  • Up to 75 AutoStem Cartridges in Series

  • Battery Type: Standard 9 Volt Battery

  • Capacity: Typically 60 firings per battery

  • Shock resistant cover

  • Very bright LED lights

  • Built in Continuity Tester with Vibration and bright LEDS

  • Unit dimensions: 89mm W x 165mm L x 30mm H

  • Unit mass: 326 grams

  • 90-Day Factory Warranty against manufacturing defects

CONTINUITY TESTER

Buzz-Mo BCT-5

  • Strong Vibrating Continuity Tester

  • Typically >800 Tests

  • Under 60µA (micro amps) max current draw

  • Testing circuit protected by 50mA fuse

  • Dustproof; waterproof; and shockproof

  • Unit dimensions: 27mm W, 50mm L, 14mm H

  • Unit mass: 70 grams

Scorpion Digital Ohmeter

DIGITAL OHMETER

Scorpion Digital Galvanometer

  • Urethane Case

  • Waterproof

  • Use a standard 9 Volt Battery

  • Range: 0 - 1999 ohms

  • Circuit: Digital

  • Unit dimensions: 76mm W, 101mm L, 38mm H

  • Unit mass: 454 grams

Accessories for Autostem

Day Box for Explosives - Certified

Day Box for Explosives.jpg

Storage Box for Explosives

  • Certified

  • Tough Inert Internal Liner

  • Lockable

  • Explosives Signage

  • Very Strong and Durable

  • Made in Australia

  • Perfect for Storing AutoStem Non-Detonating Cartridges
